IE5 Ultra Premium Efficiency 5.5kW Water Cooled Permanent Magnet Synchronous Motor for Industrial Pump

Name: IE5 Ultra Premium Efficiency 5.5kW Water Cooled Permanent Magnet Synchronous Motor for Industrial Pump
Brand: QINGDAO ENNENG MOTOR CO.,LTD.
SKU: ECER-WC-IE5-5.5
Price: 4999 USD
Availability: InStock

Brand Name:	Enneng
Model Number:	ECER-WC-IE5-5.5
MOQ:	1set
Price:	4999
Payment Terms:	T/T,L/C
Supply Ability:	5000 set

Detail Information

Product Description

Detail Information

Place of Origin:

Qingdao, China

Certification:

CE, ISO9001

Rated Power:

5.5 KW

Extreme Power:

6KW

Output Voltage:

380V

Wind Wheel Diameter:

__DELETE__

Starting Wind Speed:

__DELETE__

Tower Height:

__DELETE__

Design Life:

20 Years

Output Electricity:

2068 KG

Rated Voltage:

380V AC (customizable)

Rated Speed:

1500 Rpm

Efficiency Class:

IE5 Ultra Premium

Magnet Material:

NdFeB Rare Earth

Cooling Method:

Water Cooled (IC71W)

Protection Class:

IP55

Insulation Class:

Class H (180 C)

Mounting:

B5 Flange / B3 Foot

Frequency:

50Hz / 60Hz

Duty:

S1 Continuous

Ambient Temperature:

-20 To +50 C

Certification:

CE, ISO9001

ZZUniqKey:

Hello

Packaging Details:

Plywood wooden box

Highlight:

IE5 Water Cooled PMSM Motor

High Efficiency Permanent Magnet Motor

Low Noise Maintenance Free Motor

Product Description

IE5 Water Cooled Permanent Magnet Synchronous Motor 5.5kW

The ENNENG ECER-WC-IE5-5.5 is an IE5 ultra premium efficiency water cooled permanent magnet synchronous motor (PMSM) engineered for continuous duty industrial applications. Its sintered NdFeB rare earth magnet rotor delivers far higher torque density and lower losses than a conventional induction motor of the same frame size, while the water cooled jacket keeps winding temperature stable under heavy load.

Key Features

IE5 ultra premium efficiency class reduces power consumption and running cost
Water cooling (IC71W) maintains stable performance under continuous heavy load
High torque density in a compact, space saving frame
Low noise and low vibration for indoor and noise sensitive environments
Maintenance free brushless design with 20 year design life
VFD compatible for precise variable speed control

Technical Specifications

Rated Power	5.5 kW
Rated Voltage	380V AC (customizable)
Rated Speed	1500 rpm
Efficiency Class	IE5 Ultra Premium
Magnet Material	NdFeB Rare Earth
Cooling Method	Water Cooled (IC71W)
Protection Class	IP55
Insulation Class	Class H (180 C)

Applications

Industrial pumps, fans and blowers, compressors, mixers and other continuous duty variable torque loads.

Why Choose ENNENG

Manufactured by Qingdao Enneng Motor Co., Ltd. with CE and ISO9001 certified production, OEM/ODM customization and export experience across more than 70% overseas markets.
