IE5 7.5kW Low Noise Permanent Magnet Motor NdFeB Rare Earth Rotor for HVAC Fan Drive

Name: IE5 7.5kW Low Noise Permanent Magnet Motor NdFeB Rare Earth Rotor for HVAC Fan Drive
Brand: QINGDAO ENNENG MOTOR CO.,LTD.
SKU: ECER-NL-IE5-7.5
Price: 4999 USD
Availability: InStock

Brand Name:	Enneng
Model Number:	ECER-NL-IE5-7.5
MOQ:	1set
Price:	4999
Payment Terms:	T/T,L/C
Supply Ability:	5000 set

Detail Information

Product Description

Detail Information

Place of Origin:

Qingdao, China

Certification:

CE, ISO9001

Rated Power:

7.5 KW

Extreme Power:

6KW

Output Voltage:

380V

Wind Wheel Diameter:

Starting Wind Speed:

2.5m/s

Tower Height:

8-10 M

Design Life:

20 Years

Output Electricity:

2068 KG

Rated Voltage:

380V AC (customizable)

Rated Speed:

1500 Rpm

Efficiency Class:

IE5 Ultra Premium

Magnet Material:

NdFeB Rare Earth

Cooling Method:

Air Cooled (IC411)

Protection Class:

IP55

Insulation Class:

Class H (180 C)

Noise Level:

Low Noise Design

Mounting:

B5 Flange / B3 Foot

Frequency:

50Hz / 60Hz

Duty:

S1 Continuous

Certification:

CE, ISO9001

Packaging Details:

Plywood wooden box

Highlight:

NdFeB Rare Earth Magnet Rotor

Low Noise Permanent Magnet Motor

HVAC Fan Drive PMSM

Product Description

IE5 Low Noise Permanent Magnet Synchronous Motor 7.5kW

The ENNENG ECER-NL-IE5-7.5 is an IE5 ultra premium efficiency low noise permanent magnet synchronous motor (PMSM) built around a sintered NdFeB rare earth magnet rotor. Its smooth sinusoidal back EMF and optimised rotor geometry deliver quiet, vibration free operation, making it ideal for fans and air handling equipment in commercial buildings.

Key Features

IE5 ultra premium efficiency for significant energy saving
NdFeB rare earth magnet rotor for high power density
Low noise and low vibration operation
Maintenance free brushless construction with 20 year design life
VFD compatible for precise variable speed airflow control
Compact frame that fits existing HVAC installations

Technical Specifications

Rated Power	7.5 kW
Rated Voltage	380V AC (customizable)
Rated Speed	1500 rpm
Efficiency Class	IE5 Ultra Premium
Magnet Material	NdFeB Rare Earth
Cooling Method	Air Cooled (IC411)
Protection Class	IP55
Insulation Class	Class H (180 C)

Applications

HVAC fans, ventilation blowers, air handling units and other continuous duty fan loads.

Why Choose ENNENG

Manufactured by Qingdao Enneng Motor Co., Ltd. with CE and ISO9001 certified production, OEM/ODM customization and export experience across more than 70% overseas markets.
