EPMG-60GD 60kW Direct Drive Permanent Magnet Motor Generator 120rpm 400V

Name: EPMG-60GD 60kW Direct Drive Permanent Magnet Motor Generator 120rpm 400V
Brand: QINGDAO ENNENG MOTOR CO.,LTD.
SKU: EPMG-60GD
Price: 3.00 USD
Availability: InStock

Brand Name:	ENNENG
Model Number:	EPMG-60GD
MOQ:	1 Set
Price:	USD 1,000-5,000 / Set
Payment Terms:	L/C,T/T,Western Union,PayPal
Supply Ability:	20000 Sets per Year

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE, ISO 9001:2015

Rated Power:

60kW

Rated Voltage:

400V AC

Phase:

Three Phase

Frequency:

50Hz

Rated Speed:

120rpm

Number Of Poles:

Magnet Material:

NdFeB N42SH

Cooling Method:

Natural Cooled IC410

Protection Grade:

IP54

Bearing Brand:

SKF

Insulation Class:

Class F

Packaging Details:

Seaworthy plywood wooden case with foam shock-proof lining

Highlight:

Gearless Direct Drive PMG 60kW

50 Pole Low Speed PMG Generator

Maintenance Free Wind Turbine Generator

Product Description

EPMG-60GD 60kW Direct Drive Permanent Magnet Motor Generator 120rpm 400V

As a gearless direct drive permanent magnet motor generator, this 60kW machine removes the gearbox - the most failure-prone component in conventional wind drivetrains. The 50-pole permanent magnet motor rotor spins at only 120rpm while the generator delivers clean three phase 400V power.

EPMG-60GD 60kW Direct Drive Permanent Magnet Motor Generator Structure

Key Features

Gearless topology eliminates gearbox oil, gear noise and gear failure cost
50-pole multi-pole rotor gives high torque at low speed without speed increaser
Direct drive permanent magnetic motor construction reduces moving parts to one rotating assembly
SKF heavy-duty bearings and sealed housing rated for 20-year design life
No excitation system, no slip rings - truly maintenance free operation

Technical Specifications

Rated Power	60kW
Rated Voltage	400V AC
Phase	Three Phase
Frequency	50Hz
Rated Speed	120rpm
Number of Poles	50
Magnet Material	NdFeB N42SH
Cooling Method	Natural Cooled IC410
Protection Grade	IP54
Bearing Brand	SKF
Insulation Class	Class F

Applications

Designed for medium-size wind turbines, hybrid renewable stations and slow-speed shaft power recovery systems.

EPMG-60GD 60kW Direct Drive Permanent Magnet Motor Generator Application in Hydro Power

Quality & Warranty

Factory tested with full load curve report. CE & ISO9001 certified workshop, 2-year standard warranty with lifetime technical support.

ENNENG is an experienced permanent magnet motor and permanent magnetic motor generator manufacturer. Contact our sales team for quotation, OEM customization and technical support.
