15kW Stable Voltage Permanent Magnetic Motor Generator 250rpm 400V EPMG-15SV

Name: 15kW Stable Voltage Permanent Magnetic Motor Generator 250rpm 400V EPMG-15SV
Brand: QINGDAO ENNENG MOTOR CO.,LTD.
SKU: EPMG-15SV
Price: 3.00 USD
Availability: InStock

Brand Name:	ENNENG
Model Number:	EPMG-15SV
MOQ:	1 Set
Price:	USD 1,000-5,000 / Set
Payment Terms:	L/C,T/T,Western Union,PayPal
Supply Ability:	20000 Sets per Year

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE, ISO 9001:2015

Rated Power:

15kW

Rated Voltage:

400V AC

Phase:

Three Phase

Frequency:

50Hz / 60Hz

Rated Speed:

250rpm

Number Of Poles:

Voltage Regulation:

+/-1%

Total Harmonic Distortion:

THD Below 5%

Cooling Method:

Natural Cooled

Protection Grade:

IP54

Insulation Class:

Class H

Packaging Details:

Seaworthy plywood wooden case with foam shock-proof lining

Highlight:

15kW Permanent Magnetic Motor Generator

Three Phase 400V Stable Voltage Output

Off Grid PMG Low THD Power

Product Description

15kW Stable Voltage Permanent Magnetic Motor Generator 250rpm 400V EPMG-15SV

Voltage stability decides whether your inverter and sensitive loads survive. This 15kW three phase permanent magnet motor generator is designed as a permanent magnetic motor generator with precision balanced magnetic circuit, delivering +/-1% voltage regulation and total harmonic distortion below 5% across the working speed range.

EPMG-15SV 15kW Permanent Magnet Motor Generator Structure

Key Features

Stable voltage output from 60% to 110% rated speed - friendly to inverter charging
Low cogging torque design for smooth rotation and reduced mechanical vibration
Three phase 400V output compatible with standard grid-tie and off-grid inverters
Pure copper winding with class H insulation for reliable long-term service
Compact axial length simplifies coupling to diesel, hydro or wind prime movers

Technical Specifications

Rated Power	15kW
Rated Voltage	400V AC
Phase	Three Phase
Frequency	50Hz / 60Hz
Rated Speed	250rpm
Number of Poles	24
Voltage Regulation	+/-1%
Total Harmonic Distortion	THD below 5%
Cooling Method	Natural Cooled
Protection Grade	IP54
Insulation Class	Class H

Applications

Ideal for off-grid village electrification, telecom base station power, irrigation and hybrid diesel-PMG systems.

EPMG-15SV 15kW Permanent Magnet Motor Generator Application in Small Hydro and Irrigation Power

Quality & Warranty

Each generator ships with a no-load and rated-load test certificate. 3-year warranty and free remote troubleshooting support.

ENNENG is an experienced permanent magnet motor and permanent magnetic motor generator manufacturer. Contact our sales team for quotation, OEM customization and technical support.
