Axial Flux 20kW Permanent Magnet Motor Generator 200rpm 380V EPMG-20AX

Name: Axial Flux 20kW Permanent Magnet Motor Generator 200rpm 380V EPMG-20AX
Brand: QINGDAO ENNENG MOTOR CO.,LTD.
SKU: EPMG-20AX
Price: 3.00 USD
Availability: InStock

Brand Name:	ENNENG
Model Number:	EPMG-20AX
MOQ:	1 Set
Price:	USD 1,000-5,000 / Set
Payment Terms:	L/C,T/T,Western Union,PayPal
Supply Ability:	20000 Sets per Year

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE, ISO 9001:2015

Rated Power:

20kW

Rated Voltage:

380V AC

Phase:

Three Phase

Frequency:

50Hz

Rated Speed:

200rpm

Number Of Poles:

Topology:

Axial Flux Pancake

Cooling Method:

Natural Cooled

Protection Grade:

IP54

Magnet Material:

NdFeB Neodymium

Weight:

Lightweight Compact Design

Application:

Direct Drive Wind / Hydro

Packaging Details:

Seaworthy plywood wooden case with foam shock-proof lining

Highlight:

20kW Axial Flux PMG Direct Drive

Compact Pancake Permanent Magnetic Motor Generator

200rpm Low Cogging Wind Generator

Product Description

Axial Flux 20kW Permanent Magnet Motor Generator 200rpm 380V EPMG-20AX

Space and weight matter when the generator sits inside a nacelle or on a penstock. This 20kW axial flux direct drive permanent magnetic motor generator uses a pancake topology that shortens the drivetrain dramatically - the whole permanent magnet motor generator is thinner and lighter than a conventional radial machine of equal power.

EPMG-20AX 20kW Axial Flux Permanent Magnet Motor Generator Structure

Key Features

Axial flux pancake construction shortens axial length and reduces nacelle size
Direct drive at 200rpm - no gearbox, no speed increaser needed
Low cogging torque gives smooth start-up in light wind or low water flow
Lightweight design eases tower-top handling and installation
Double-sided rotor configuration increases torque density

Technical Specifications

Rated Power	20kW
Rated Voltage	380V AC
Phase	Three Phase
Frequency	50Hz
Rated Speed	200rpm
Number of Poles	30
Topology	Axial Flux Pancake
Cooling Method	Natural Cooled
Protection Grade	IP54
Magnet Material	NdFeB Neodymium
Weight	Lightweight Compact Design
Application	Direct Drive Wind / Hydro

Applications

Popular for small wind turbines, pico-micro hydro sets and direct-drive retrofits of existing turbine shafts.

EPMG-20AX 20kW Axial Flux Permanent Magnet Motor Generator Application

Quality & Warranty

CE & ISO9001 certified workshop, 2-year warranty, custom diameter and pole count available for your rotor interface.

ENNENG is an experienced permanent magnet motor and permanent magnetic motor generator manufacturer. Contact our sales team for quotation, OEM customization and technical support.
