100kW Radial Flux Direct Drive Permanent Magnet Generator for Wind Turbines 120rpm 690V

Name: 100kW Radial Flux Direct Drive Permanent Magnet Generator for Wind Turbines 120rpm 690V
Brand: QINGDAO ENNENG MOTOR CO.,LTD.
SKU: PMG-100RF
Price: 11.00 USD
Availability: InStock

Brand Name:	ECER
Model Number:	PMG-100RF
MOQ:	1 Set
Price:	USD 9,500-14,000 / Set
Payment Terms:	T/T,L/C,Western Union
Supply Ability:	100 Sets per Month

Detail Information

Product Description

Detail Information

Place of Origin:

Fujian, China

Certification:

CE, ISO 9001:2015

Flux Type:

Radial Flux

Cooling Method:

Air Cooled (IC411)

Rated Speed:

120rpm

Phase:

3 Phase

Insulation Class:

Class H (180C)

Efficiency:

96%

Number Of Poles:

Rated Voltage:

690V AC

Frequency:

50Hz

Rated Power:

100kW

Protection Class:

IP54

Torque Density:

High

Packaging Details:

Export plywood case with shock-proof foam and waterproof wrapping, suitable for sea freight

Highlight:

Radial Flux Direct Drive PMG

100kW 690V Wind Generator

Low Speed 120rpm PM Generator

Product Description

100kW Radial Flux Direct Drive Permanent Magnet Generator 120rpm 690V Wind PMG

100kW Radial Flux Direct Drive Permanent Magnet Generator

This 100kW radial flux direct drive permanent magnet generator adopts a 64 pole rotor to generate 690V three phase power at only 120rpm, eliminating the gearbox in wind turbine drivetrains. The radial flux topology offers mature manufacturing process, high torque density and reliable mechanical structure.

With 96% efficiency and air cooled IC411 design, this permanent magnetic generator is widely used in mid-size wind turbines and low head hydro projects. All windings are vacuum impregnated with class H insulation for long term outdoor service.

Key Features

Radial flux multi-pole structure with high torque density
Direct drive at 120rpm, gearbox free drivetrain
690V output reduces cable loss in power transmission
96% efficiency at rated operating point
Vacuum impregnated class H windings
Air cooled IC411, no external water source required

Structure Diagram

PMG-100RF Permanent Magnet Generator Structure Diagram

Technical Specifications

Rated Power	100kW
Rated Speed	120rpm
Rated Voltage	690V AC
Frequency	50Hz
Phase	3 Phase
Number of Poles	64
Efficiency	96%
Flux Type	Radial Flux
Insulation Class	Class H (180°C)
Protection Class	IP54
Cooling Method	Air Cooled (IC411)
Application	Wind / Hydro

Application Scene

PMG-100RF Permanent Magnet Generator Application Scene

Typical Applications

Mid-size wind turbines, low head hydro turbines, industrial shaft power recovery, distributed renewable power generation.

We provide complete electromagnetic design and mechanical drawings for project integration. Contact us for the quotation.
