20kW Axial Flux Permanent Magnet Generator 200rpm for Micro Hydro Stations

Name: 20kW Axial Flux Permanent Magnet Generator 200rpm for Micro Hydro Stations
Brand: QINGDAO ENNENG MOTOR CO.,LTD.
SKU: PMG-20AF
Price: 3.00 USD
Availability: InStock

Brand Name:	ECER
Model Number:	PMG-20AF
MOQ:	1 Set
Price:	USD 2,800-4,200 / Set
Payment Terms:	T/T,L/C,Western Union
Supply Ability:	100 Sets per Month

Detail Information

Product Description

Detail Information

Place of Origin:

Fujian, China

Certification:

CE, ISO 9001:2015

Rated Voltage:

380V AC

Rated Speed:

200rpm

Phase:

3 Phase

Insulation Class:

Class H (180C)

Efficiency:

93%

Number Of Poles:

Flux Type:

Axial Flux

Cooling Method:

Natural Cooled

Frequency:

50Hz

Rated Power:

20kW

Protection Class:

IP54

Output Voltage:

380V

Packaging Details:

Export plywood case with shock-proof foam and waterproof wrapping, suitable for sea freight

Highlight:

Axial Flux Coreless PMG Generator

20kW Micro Hydro Generator

200rpm Axial Permanent Magnet Generator

Product Description

20kW Axial Flux Permanent Magnet Generator 200rpm 380V Micro Hydro Station PMG

20kW Axial Flux Permanent Magnet Generator

This 20kW axial flux permanent magnet generator features a slim disc rotor structure that fits directly onto the turbine shaft of micro hydro stations. The axial flux design shortens the magnetic path and increases power density, making the generator lightweight and easy to install in restricted spaces.

The generator produces 380V 50Hz three phase power at 200rpm and operates with 93% efficiency. As a permanent magnetic generator with no field windings, it keeps stable output voltage across variable water flow conditions, protecting downstream inverter equipment.

Key Features

Slim axial flux disc design, light weight and compact
Direct shaft mounting for micro hydro turbines
40 pole rotor for 200rpm low speed generation
Stable output under variable water flow
No field windings, no slip rings, maintenance free
Natural cooled, silent operation

Structure Diagram

PMG-20AF Permanent Magnet Generator Structure Diagram

Technical Specifications

Rated Power	20kW
Rated Speed	200rpm
Rated Voltage	380V AC
Frequency	50Hz
Phase	3 Phase
Number of Poles	40
Efficiency	93%
Flux Type	Axial Flux
Insulation Class	Class H (180C)
Protection Class	IP54
Cooling Method	Natural Cooled
Application	Micro Hydro

Application Scene

PMG-20AF Permanent Magnet Generator Application Scene

Typical Applications

Micro hydro power stations
Pico hydro turbines
Ducted water turbines
Low speed renewable generation

Hollow shaft and flange options are available for direct turbine coupling. Contact our engineers for dimension drawings.
