15kW 250rpm 400V Three Phase Permanent Magnet Generator with Built-in AVR for Off Grid Power

Name: 15kW 250rpm 400V Three Phase Permanent Magnet Generator with Built-in AVR for Off Grid Power
Brand: QINGDAO ENNENG MOTOR CO.,LTD.
SKU: PMG-15AV
Price: 2.00 USD
Availability: InStock

Brand Name:	ECER
Model Number:	PMG-15AV
MOQ:	1 Set
Price:	USD 2,200-3,200 / Set
Payment Terms:	T/T,L/C,Western Union
Supply Ability:	100 Sets per Month

Detail Information

Product Description

Detail Information

Place of Origin:

Fujian, China

Certification:

CE, ISO 9001:2015

Rated Speed:

250rpm

Number Of Poles:

Voltage Regulation:

+/- 1%

Protection Class:

IP54

Rated Voltage:

400V AC

Phase:

3 Phase

AVR:

Built-in

Efficiency:

93%

Rated Power:

15kW

Insulation Class:

Class H (180C)

Frequency:

50Hz

Cooling Type:

Natural Cooled

Packaging Details:

Export plywood case with shock-proof foam and waterproof wrapping, suitable for sea freight

Highlight:

Stable Voltage AVR PMG Generator

15kW Off Grid Power Generator

250rpm 400V Three Phase PMG

Product Description

15kW Stable Voltage Permanent Magnet Generator AVR 250rpm 400V Three Phase PMG

15kW Stable Voltage Permanent Magnet Generator

This 15kW permanent magnet generator integrates an automatic voltage regulator (AVR) that holds output voltage within ±1%, protecting sensitive household and telecom loads in off-grid power systems. The generator runs at 250rpm and delivers stable 400V 50Hz three-phase power.

Compared with a common permanent magnetic generator, the AVR-equipped version is the preferred choice for standalone wind and hydro systems where load changes frequently. It also reduces the burden on downstream inverters and battery chargers.

Key Features

Built-in AVR keeps voltage regulation within ±1%
Suitable for frequent load changes in off-grid systems
24 pole low speed design at 250rpm
Three phase 400V output, easy to wire
Class H insulation, natural cooled body
Complete protection for household and telecom loads

Structure Diagram

PMG-15AV Permanent Magnet Generator Structure Diagram

Technical Specifications

Rated Power	15kW
Rated Speed	250rpm
Rated Voltage	400V AC
Frequency	50Hz
Phase	3 Phase
Number of Poles	24
Efficiency	93%
Voltage Regulation	±1%
AVR	Built-in
Insulation Class	Class H (180°C)
Protection Class	IP54
Application	Off Grid Power

Application Scene

PMG-15AV Permanent Magnet Generator Application Scene

Typical Applications

Off-grid wind and hydro power systems, remote villages, telecom base stations, backup renewable power for farms.

The AVR setting can be adjusted according to your inverter requirements. Contact us for the wiring diagram.
