IP68 Waterproof 15KW Permanent Magnet Motor for Submersible Sewage Pump Stations

Name: IP68 Waterproof 15KW Permanent Magnet Motor for Submersible Sewage Pump Stations
Brand: QINGDAO ENNENG MOTOR CO.,LTD.
SKU: ECER-IP68-15
Price: Negotiable USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: ECER PMM

Certification: CE, ISO9001

Model Number: ECER-IP68-15

Payment & Shipping Terms

Minimum Order Quantity: 1 set

Price: Negotiable

Packaging Details: Export wooden case with moisture barrier and desiccant

Delivery Time: 25-35 days

Payment Terms: T/T,L/C

Supply Ability: 500 sets per month

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                                                                                                                                    IP68 submersible sewage pump motor, waterproof permanent magnet drive, corrosion resistant submersible motor


Protection Grade:	IP68 Submersible	Mounting Type:	B5 Flange, Vertical
Frequency:	50 Hz	Rated Voltage:	380 V AC, Three Phase
Rated Speed:	600 Rpm	Insulation Class:	Class H
Cooling Method:	IC410 Self Cooled	Cable Entry:	Waterproof Gland
Efficiency Class:	IE4 / IE5	Rated Power:	15 KW
Shaft Seal:	Double Mechanical Seal	Number Of Poles:	10 Poles

Protection Grade:	IP68 Submersible
Mounting Type:	B5 Flange, Vertical
Frequency:	50 Hz
Rated Voltage:	380 V AC, Three Phase
Rated Speed:	600 Rpm
Insulation Class:	Class H
Cooling Method:	IC410 Self Cooled
Cable Entry:	Waterproof Gland
Efficiency Class:	IE4 / IE5
Rated Power:	15 KW
Shaft Seal:	Double Mechanical Seal
Number Of Poles:	10 Poles

IP68 Waterproof 15KW Permanent Magnet Motor for Submersible Sewage Pump Stations

The ECER-IP68-15 is a fully submersible 15 kW Permanent Magnet Motor engineered for sewage lift stations, deep well pumps and flood prone plant rooms where standard motors fail quickly. Its IP68 enclosure allows continuous operation even when completely submerged, while the Permanent Magnetic Motor design delivers IE4/IE5 level efficiency with high starting torque.

Sealing is provided by O ring sealed terminal boxes, a double mechanical shaft seal and a waterproof cable gland, keeping moisture and grit away from the windings in the most aggressive wet environments.

Key Features

IP68 Total Submersion: rated for continuous underwater duty in sewage and storm water applications.
Corrosion Protection: marine grade paint and corrosion resistant shaft withstand sewage gas and salt water.
Energy Saving: the Permanent Magnet Motor cuts power use versus induction motors in long running pump duty.
Low Speed High Torque: 10 pole rotor starts heavy impellers directly without oversizing.
Low Maintenance: brushless construction and sealed bearings reduce service intervals.

Technical Specifications

Parameter	Specification
Rated Power	15 kW
Rated Voltage	380 V AC, three phase
Frequency	50 Hz
Number of Poles	10 poles
Rated Speed	600 rpm
Efficiency Class	IE4 / IE5
Cooling Method	IC410 self cooled
Protection Grade	IP68 submersible
Shaft Seal	Double mechanical seal
Mounting Type	B5 flange, vertical

Applications

This Permanent Magnet Motor is designed for submersible sewage pumps, storm water pumps, deep well pumps, aquaculture aeration and marine bilge systems. Municipal water utilities and agricultural projects benefit from its corrosion resistance, low noise and reduced energy bills over long pumping hours.

Packaging & Quality Assurance

Every unit passes a submersion test, insulation test, load test and noise test before shipment. Export wooden case packing with moisture barrier protects the motor in transit. An 18 month warranty and permanent spare parts support are provided.
