250KW IE5 Ultra Premium Permanent Magnet Motor Drop-In Retrofit for Induction Replacement

Name: 250KW IE5 Ultra Premium Permanent Magnet Motor Drop-In Retrofit for Induction Replacement
Brand: QINGDAO ENNENG MOTOR CO.,LTD.
SKU: ECER-RT-250
Price: 18,750.00 USD
Availability: InStock

Brand Name:	ECER
Model Number:	ECER-RT-250
MOQ:	1 Piece
Price:	USD 12500-25000 / Piece
Payment Terms:	T/T,L/C,Western Union
Supply Ability:	100 Sets per Month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE, ISO 9001

Rated Voltage:

380V / 660V

Rated Speed:

1500RPM

Insulation Class:

Class H

Protection Class:

IP55

Retrofit Base:

IE2 / IE3 Induction Frame

Pole Number:

4 Poles

Cooling Method:

IC411 Forced Fan Cooled

Magnet Type:

NdFeB Rare Earth

Frequency:

50Hz

Rated Power:

250KW

Mounting Type:

B3 Drop-In IEC Frame

Efficiency Class:

IE5 Ultra Premium

Packaging Details:

Export plywood case with foam protection

Highlight:

Drop-In Induction Replacement

IE5 Retrofit Energy Saving

High Power Retrofit Drive

Product Description

250KW IE5 Drop-In Retrofit Permanent Magnetic Motor for Induction Replacement

Product Overview

The ECER-RT-250 is a 250KW IE5 Permanent Magnetic Motor designed as a drop-in retrofit replacement for oversized or ageing induction motors. Matching the standard IEC frame footprint, shaft height and terminal arrangement, this Permanent Magnetic Motor lets plants upgrade without reworking foundations, couplings or electrical panels.

Fig.1 250KW IE5 Permanent Magnet Motor Structure Diagram

Key Features

Drop-in retrofit matches existing IEC frame and shaft dimensions
Eliminates rotor and slip losses of induction motors
Up to 30% energy saving on continuous duty applications
No foundation or coupling modification required
Fast payback through reduced electricity consumption

Technical Specifications

Rated Power	250KW
Rated Voltage	380V / 660V
Frequency	50Hz
Efficiency Class	IE5 Ultra Premium
Rated Speed	1500RPM
Pole Number	4 Poles
Protection Class	IP55
Cooling Method	IC411 Forced Fan Cooled
Insulation Class	Class H
Mounting Type	B3 Drop-In IEC Frame
Magnet Type	NdFeB Rare Earth
Retrofit Base	IE2 / IE3 Induction Frame

Applications

Perfect for pumps, fans, compressors, conveyors and mixers currently driven by induction motors, where a drop-in retrofit Permanent Magnet Motor upgrades efficiency with minimal downtime.

Fig.2 Drop-In Retrofit Permanent Magnetic Motor in Industrial Application

Quality Assurance

Retrofit dimensions are verified against your existing motor before production, and every Permanent Magnetic Motor ships with full test reports under ISO9001 certification and warranty.

Model ECER-RT-250 is available for worldwide export. Ask our retrofit engineers for a free energy saving assessment and quote.
