100KW Variable Frequency Permanent Magnet Generator with IE4 Efficiency for Wind and Hydro Power

Brand Name:	ECER PMM
MOQ:	1 Set
Price:	Negotiable
Payment Terms:	T/T,L/C
Supply Ability:	500 Sets per Month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE, ISO9001

Insulation Class:

Class F

Frequency:

Variable

Rated Voltage:

400V

Magnet Material:

NdFeB Rare Earth

Protection Grade:

IP54

Converter Duty:

VFD Compatible

Speed Range:

150-1500 RPM

Cooling Method:

IC416 Forced Ventilation

Ambient Temperature:

-15C To +45C

Rated Power:

100KW

Mounting Type:

IMB3

Efficiency Class:

IE4

Packaging Details:

Export wooden case packaging

Highlight:

VFD Compatible Generator

IE4 Energy Saving Generator

100KW Variable Speed Generator

Product Description

Variable Frequency 100KW Permanent Magnetic Generator IE4 Efficiency Drive

Product Overview

This 100KW permanent magnetic generator is engineered for variable frequency operation. The rotor utilizes rare earth magnets, enabling the generator to maintain stable voltage across a wide speed range. This makes it ideally suited for variable speed wind, hydro, and waste heat recovery systems when combined with a frequency converter.

Key Features

Designed for VFD and converter driven variable speed systems
IE4 efficiency class with low losses across the speed range
Stable output voltage over a wide speed range
Forced ventilation cooling for continuous duty
Compact frame with high power density

Working Principle

Permanent Magnet Generator Working Principle Diagram

Technical Specifications

Parameter	Value
Rated Power	100KW
Rated Voltage	400V AC
Speed Range	150-1500 RPM
Efficiency Class	IE4
Magnet Material	NdFeB Rare Earth
Converter Duty	VFD Compatible
Insulation Class	Class F
Cooling	IC416 Forced Ventilation
Protection Grade	IP54
Mounting	IMB3

Applications

Variable speed wind power, micro hydro power, waste heat recovery, ORC power generation and industrial power conversion.

Permanent Magnet Generator Machine Application

Ordering Information

The 100KW variable speed generator can be matched to your converter and working speed range. Please provide your specific speed and voltage requirements, then request a quotation and datasheet.
